Wireless Bridge Calculator

Determine whether a point-to-point wireless bridge is feasible between two locations. This calculator combines FSPL, antenna gains, cable losses, and receiver sensitivity into a single pass/fail analysis with detailed link budget and Fresnel zone requirements.

What Is a Wireless Bridge?

A wireless bridge creates a point-to-point network connection between two locations without physical cabling. It replaces the need for expensive fiber or leased lines by using directional antennas and high-gain radios to transmit data over distances from hundreds of meters to tens of kilometers. Bridges are commonly used to connect buildings, extend networks to outbuildings, or provide internet to remote locations.

A successful bridge requires a positive link budget, clear Fresnel zone, and properly aimed high-gain antennas. Our calculator combines all these factors into a single feasibility analysis, telling you whether your bridge will work and how much margin you have.

Bridge Planning Checklist

Before deploying a wireless bridge, complete these planning steps. Each step involves a different calculation tool — this bridge calculator brings them all together for a final verdict:

Pro Tip: For bridges under 1 km in an urban environment, integrated radio/antenna units (like Ubiquiti NanoBeam or MikroTik SXTsq) are the simplest solution — they eliminate cable loss entirely and come pre-aligned. For longer links (5+ km), dedicated parabolic dishes with separate radios give you more flexibility and higher gain. Always verify with the Antenna Gain Calculator that your EIRP stays within regulatory limits.

Frequency Selection for Bridges

Choosing the right frequency band is critical for bridge performance. Lower frequencies travel farther but offer less bandwidth; higher frequencies provide more throughput but require larger Fresnel zone clearance and more precise alignment:

Common Bridge Configurations

These typical configurations give you a starting point. Adjust values based on your specific equipment specs. The key is matching the right antenna and power level to your distance and throughput requirements:

Troubleshooting Bridge Issues

If your bridge calculator shows a passing link but real-world performance is poor, check these common issues. Many parallel the troubleshooting process for slow WiFi:

• Antenna misalignment — Even 2 degrees of misalignment can cost 10+ dB with high-gain dishes. Use alignment tools.
• Fresnel zone obstruction — Trees or buildings intruding on the Fresnel zone add loss not shown in the basic link budget.
• Interference — Use a channel finder to detect competing signals. Switch to a cleaner channel or use DFS channels.
• Cable degradation — Water ingress into coax connectors increases loss dramatically. Use weatherproof connectors and drip loops.
• Wrong channel width — Wider channels (40/80 MHz) increase throughput but also increase noise floor, reducing range.
• Power too high — Surprisingly, excessive Tx power can overdrive the nearby receiver. Reduce power if the link is short.

After troubleshooting, validate with a speed test, ping test, and What Is My IP to confirm full connectivity. Secure the bridge with a strong password and dedicated management VLAN.

Bridge vs Alternative Solutions

A wireless bridge is not always the best solution. Consider these alternatives based on your situation:

• Mesh WiFi — For distances under 30 meters with clear sight, a mesh WiFi outdoor node is simpler. See mesh vs extender.
• Ethernet cable — For distances under 100 meters, Cat5e/Cat6 cable is more reliable and cheaper. Use the Cable Length Calculator.
• Range extender — For moderate distances with existing WiFi, an extender may suffice.
• Access point mode — AP mode on a second router provides wired backhaul coverage without bridge equipment.
• Fiber — For permanent, high-bandwidth needs, buried fiber is the gold standard (but expensive).

Video: How to Set Up a Wireless Bridge

Related Tools and Guides

• Link Budget Calculator
• Free Space Path Loss Calculator
• Fresnel Zone Calculator
• Antenna Gain Calculator
• WiFi Coverage Estimator
• Signal Strength Converter
• Ping Test
• How to Connect Two Routers
• How to Extend WiFi Range
• Ubiquiti Link Calculator

Frequently Asked Questions

How far can a wireless bridge reach?

With high-gain parabolic antennas (30+ dBi) at 5.8 GHz, bridges can span 30+ kilometers with proper line of sight. Consumer-grade equipment typically maxes out at 5-10 km. The calculator's "Maximum Distance" table shows your specific equipment's limits at various fade margins.

What fade margin should I target for a bridge?

Minimum 10 dB for non-critical links, 15-20 dB for production links, and 25+ dB for critical infrastructure. This margin accounts for rain fade, atmospheric changes, antenna sway in wind, and equipment aging over time.

Do both sides of the bridge need the same equipment?

No, but they must operate on the same frequency and protocol. The transmit side and receive side can have different antenna gains and transmit powers. However, using matching equipment simplifies configuration and ensures symmetrical performance in both directions.

Can I bridge over water?

Yes, and water surfaces actually help because they provide excellent RF reflection that can boost signal. However, the reflection can also cause multipath interference. Elevate antennas high enough to avoid ground-bounce cancellation — typically 15+ meters for long water crossings.

Is a wireless bridge secure?

Modern bridges support WPA2/WPA3 encryption, making them as secure as any WiFi connection. For additional security, use a dedicated VLAN, MAC filtering, and a strong password. Point-to-point links are inherently harder to intercept than omnidirectional broadcasts since the signal is focused in a narrow beam.

What is the difference between a bridge and a repeater?

A bridge creates a dedicated link between two specific points, typically with directional antennas for maximum range and throughput. A repeater (or extender) rebroadcasts an existing WiFi signal omnidirectionally, typically halving the throughput. Bridges are far superior for connecting two specific locations.

How do I align bridge antennas?

Most bridge radios include an alignment tool in their web interface that shows received signal strength in real-time. Start with rough visual alignment using landmarks, then fine-tune by slowly adjusting azimuth (horizontal) and elevation (vertical) while monitoring signal strength. A continuous ping helps detect drops during adjustment.
