Free Space Path Loss Calculator

Calculate the signal attenuation of a wireless link using the Friis transmission equation. Enter distance and frequency to determine the free space path loss (FSPL) in decibels. This is the foundation of every link budget calculation and wireless bridge design.

What Is Free Space Path Loss?

Free space path loss (FSPL) is the attenuation of radio signal energy as it propagates through free space — an idealized environment with no obstacles, reflections, or atmospheric effects. It represents the minimum possible signal loss for any wireless link and serves as the baseline for all link budget calculations.

In real-world conditions, actual path loss is always higher than FSPL due to wall attenuation, ground reflections, atmospheric absorption, and Fresnel zone obstructions. However, FSPL gives you the theoretical best case, which is the starting point for determining whether a wireless link is feasible. Our WiFi Coverage Estimator applies additional loss factors for indoor environments.

The FSPL Formula

The free space path loss equation comes from the Friis transmission formula and depends on only two variables — distance and frequency:

FSPL (dB) = 20·log₁₀(d) + 20·log₁₀(f) + 32.44

Where:
  d = distance in kilometers
  f = frequency in MHz
  32.44 = constant derived from (4π/c)²

Key insight: every time you double the distance, FSPL increases by 6 dB. Every time you double the frequency, FSPL also increases by 6 dB. This is why 5 GHz WiFi has shorter range than 2.4 GHz — the higher frequency inherently loses more energy over the same distance.

FSPL Reference Table

This table shows FSPL values for common wireless scenarios. Use these as quick references when planning your antenna and bridge configurations:

Pro Tip: When comparing 2.4 GHz and 5 GHz for the same distance, 5 GHz has about 6.4 dB more path loss. This means 5 GHz needs approximately 4x more power (or 4x more antenna gain) to achieve the same received signal. That is exactly why dual-band routers use higher transmit power on 5 GHz. Factor this into your router placement decisions.

Relationship to Link Budget

FSPL is one component of a complete link budget. The full equation for a wireless link is:

Received Power = Tx Power + Tx Antenna Gain - Tx Cable Loss - FSPL - Additional Losses + Rx Antenna Gain - Rx Cable Loss

The received power must exceed the receiver's sensitivity threshold for the link to work. Use our Antenna Gain Calculator to determine your EIRP, then subtract the FSPL from this calculator to estimate whether your signal will arrive above the receiver's minimum sensitivity.

Distance-Loss Relationship

FSPL follows the inverse-square law. This has practical implications for network planning and explains why dead zones often appear at specific distances from the router:

Frequency and Wavelength

Higher frequencies experience more path loss because their shorter wavelengths capture less energy at the receiving antenna. Understanding this relationship is critical for choosing the right band for your application and selecting appropriate antennas:

• 900 MHz — Longest range, best wall penetration. Used for IoT (LoRa), cellular, and some ISP backhaul.
• 2.4 GHz — Good range, moderate wall penetration. Standard WiFi and Bluetooth.
• 5 GHz — Shorter range, poor wall penetration, but much higher throughput. Preferred for WiFi 6 performance.
• 6 GHz — Shortest WiFi range, minimal wall penetration, maximum bandwidth. WiFi 6E only.
• 60 GHz — Room-level range only. Ultra-high bandwidth (WiGig), blocked by walls entirely.

For a quick bandwidth and throughput check after setting up your link, run our Speed Test or verify connectivity with What Is My IP.

Compensating for Path Loss

When FSPL threatens to make your link unviable, these strategies recover signal margin. Increasing antenna gain is usually the most cost-effective approach. Our Signal Strength Converter helps translate between measurement units when evaluating options:

1. Increase antenna gain — Every 3 dBi of additional gain doubles effective range. Use a higher-gain directional antenna.
2. Reduce distance — Halving the distance reduces loss by 6 dB. Consider adding a relay point or extender.
3. Lower frequency — Switch from 5 GHz to 2.4 GHz to gain ~6 dB at the same distance.
4. Increase Tx power — Within regulatory limits, boosting transmit power directly compensates for path loss.
5. Use wired backhaul — Run Ethernet cable (check with the Cable Length Calculator) for part of the link.
6. Improve receiver sensitivity — Better radios can decode weaker signals (lower noise floor).

Video: Understanding RF Path Loss

Related Tools and Guides

• Link Budget Calculator
• Antenna Gain Calculator
• Fresnel Zone Calculator
• Wireless Bridge Calculator
• WiFi Coverage Estimator
• Signal Strength Converter
• Bluetooth Range Calculator
• 2.4 GHz vs 5 GHz WiFi
• How to Extend WiFi Range
• ITU-R P.525 — Free Space Path Loss Model

Frequently Asked Questions

What is the free space path loss formula?

FSPL (dB) = 20·log₁₀(d) + 20·log₁₀(f) + 32.44, where d is distance in kilometers and f is frequency in MHz. This equation comes from the Friis transmission formula and represents the minimum theoretical signal loss for a wireless link.

Why does 5 GHz WiFi have shorter range than 2.4 GHz?

Higher frequencies have more free space path loss. At 5 GHz, the FSPL is about 6.4 dB higher than at 2.4 GHz for the same distance. This means 5 GHz signals arrive about 4x weaker, which directly reduces usable range. That is why dual-band routers use 2.4 GHz for range and 5 GHz for speed.

Does FSPL account for walls and obstacles?

No. FSPL only models loss in a perfect vacuum or unobstructed air. Real environments add loss from walls (3-15 dB each), floors (10-15 dB), furniture, and atmospheric conditions. Use our WiFi Coverage Estimator for indoor scenarios that include wall attenuation.

How do I calculate the maximum range of my WiFi?

Start with your transmit EIRP (from the Antenna Gain Calculator), subtract the receiver sensitivity, and the result is your available path loss budget. Then use the FSPL formula to find the maximum distance where loss equals your budget.

What is the relationship between FSPL and the inverse-square law?

FSPL is the mathematical expression of the inverse-square law for electromagnetic radiation. Signal power decreases proportional to the square of the distance — doubling distance quarters the received power (+6 dB loss).

Can FSPL be negative?

Technically yes, at very short distances and low frequencies (e.g., a few centimeters at 100 MHz). But in practical wireless networking scenarios, FSPL is always a positive value representing signal loss.
