Understand how the Address Resolution Protocol (ARP) works with an interactive simulation. Watch ARP requests and replies in action, see how MAC addresses are resolved, and learn to read ARP tables — essential knowledge for network troubleshooting and security.
| IP Address | MAC Address | Type | Age (sec) |
|---|
The Address Resolution Protocol (ARP) maps IP addresses to MAC (hardware) addresses on a local network. When your computer wants to communicate with another device on the same subnet, it needs the destination's MAC address to create an Ethernet frame. ARP provides this mapping by broadcasting a request and caching the response.
ARP operates at Layer 2/3 boundary and is fundamental to how Ethernet networks function. Every time you access your router at 192.168.1.1, your computer uses ARP to find the router's MAC address. Use our Subnet Calculator to understand which devices are on the same subnet (and thus use ARP directly).
| Step | Action | Frame Details |
|---|---|---|
| 1. Check cache | Computer checks local ARP table for target IP | No network traffic |
| 2. ARP Request | If not cached, broadcast "Who has [IP]?" | Dst: FF:FF:FF:FF:FF:FF (broadcast) |
| 3. All devices receive | Every device on the subnet processes the request | Only target IP responds |
| 4. ARP Reply | Target responds with its MAC address | Unicast reply to requester |
| 5. Cache entry | Requester adds IP→MAC mapping to ARP table | Cached for 1-20 minutes (OS dependent) |
| 6. Communication | Ethernet frames now use resolved MAC address | Direct unicast communication |
| Type | Description | Lifetime | Created By |
|---|---|---|---|
| Dynamic | Learned via ARP request/reply | 1-20 minutes (varies by OS) | Normal ARP resolution |
| Static | Manually configured, persistent | Until removed or reboot | Admin configuration |
| Incomplete | ARP request sent, no reply yet | ~3 seconds | Pending resolution |
| Proxy ARP | Router answers on behalf of remote host | Like dynamic entries | Router feature |
Pro Tip: If you see duplicate MAC addresses for different IPs in your ARP table, this could indicate an ARP spoofing attack or a misconfigured network. Static ARP entries for critical infrastructure (routers, servers) prevent ARP poisoning attacks. On your router at 192.168.1.1, look for ARP binding features in the security settings.
# Windows
arp -a
# Linux
arp -n
# or (modern)
ip neigh show
# macOS
arp -a
# Cisco IOS
show ip arp
# Clear ARP cache
# Windows: arp -d *
# Linux: sudo ip neigh flush allAfter checking your ARP table, use our DNS Lookup to verify DNS resolution is also working correctly, and our Ping Test to confirm connectivity to resolved hosts.
ARP has no built-in authentication, making it vulnerable to several attacks:
| Attack | Description | Impact | Prevention |
|---|---|---|---|
| ARP Spoofing | Attacker sends fake ARP replies | Traffic interception (MITM) | Static ARP, Dynamic ARP Inspection |
| ARP Poisoning | Corrupts ARP cache of victims | Redirect traffic to attacker | 802.1X, port security |
| ARP Flooding | Floods switch with ARP packets | Switch reverts to hub (broadcasts all) | Rate limiting, port security |
| Gratuitous ARP | Unsolicited ARP announcements | IP conflict detection, but exploitable | DAI on managed switches |
For network security beyond ARP, check your firewall and NAT configuration. Use network traffic monitoring to detect suspicious ARP activity. Verify open ports with our Port Checker.
IPv6 replaces ARP with the Neighbor Discovery Protocol (NDP), which uses ICMPv6 instead of a separate protocol:
| Feature | ARP (IPv4) | NDP (IPv6) |
|---|---|---|
| Layer | Layer 2/3 | Layer 3 (ICMPv6) |
| Resolution | IP → MAC | IPv6 → MAC |
| Discovery | Broadcast | Multicast (solicited-node) |
| Security | None (exploitable) | SEND (optional crypto) |
| Extra Features | None | Router discovery, SLAAC, DAD |
The ARP table (or ARP cache) is a local database that maps IP addresses to MAC addresses. Your computer checks this table before sending any data on the local network. If the destination isn't in the table, an ARP request is broadcast to find the MAC address.
Dynamic ARP entries expire after a timeout period: Windows defaults to 15-45 seconds of inactivity, Linux defaults to 30-60 seconds, and macOS defaults to 20 minutes. Static entries persist until manually removed or system reboot.
ARP spoofing (or ARP poisoning) is an attack where a malicious device sends fake ARP replies to associate its MAC address with another device's IP. This redirects traffic through the attacker, enabling man-in-the-middle attacks. Prevent with static ARP entries or Dynamic ARP Inspection on switches.
ARP uses Ethernet broadcast frames (FF:FF:FF:FF:FF:FF), which don't cross router boundaries. For devices on remote subnets, your computer ARPs for the gateway MAC address, and the router forwards packets to the remote subnet using its own ARP table.
A Gratuitous ARP is an unsolicited ARP reply sent by a device announcing its own IP-to-MAC mapping. It's used for duplicate IP detection, updating ARP caches after MAC address changes, and failover in high-availability setups.
Enable Dynamic ARP Inspection (DAI) on managed switches, use VLANs to limit broadcast domains, configure DHCP snooping, and add static ARP entries for critical infrastructure. Monitor network traffic for unusual ARP patterns.
